Model No. FPC-3000AL

Input Data (AC)

• Max. DC Voltage : 16 V
• Max. DC Current : 32 A

Output Data (AC)

• Max. AC Power : 0.6 kW
• Output AC Voltage Range : 215~235 V
• Frequency : 50, 60 Hz
• Power Factor (cosθ) : 0.98
• Distortion (THD) : < 3 %
• Max. Efficiency : 85 %

General Data

• Dimensions (H/W/D) : 200x94x55 mm
• Weight : 0.69 kg
• Operating Temperature : -20 ~ +60 ℃
• Humidity : 10-90 %
• Cooling : Natural
• Interface : USB
• Display : LED
• Protection Feature : Short Circuit Protection, Overload Protection, Reverse Polarity Protection
